Electric Male Female Pluggable Wire Connectors PS2A-N3

UL 94V-2 PA66 Black IP30 Protection Degree shell, 3 Poles Multipolar Thin Type Pluggable Wire Connectors. Connector specification: size of connector: 121.50mm×28.50mm×12.50mm Annual Production: 40, 000, 000PCS/Year Materials: housing: polyamide66(v2) clamping unit: copper/brass Packing info: 400 pcs per carton carton size: 62.5×40×22 cm net weight: 11.5kg gross weight: 13kg     Dimensions   Specification Item No. PS2A-N3 Electrical Data   IEC/EN UL Rated Voltage (V) 250 600 Rated Current (A) 16 16 Ambient Temperature Polyamide 66 90℃ 105℃ Connection Data   IEC/EN UL Cross Section Solid conductor 0.75-2.5mm² AWG 14-18 Stranded conductor 0.75-2.5mm² AWG 14-18 Flexible conductor 0.75-2.5mm² AWG 14-18 Strip length (mm) 7  Means of connection screw fixed Screw M3 Rewirable √ Number of terminals multiway Number of connection points 3 Prot…
